IPC Ravena Swimming Pool Enclosure

The shape of the Ravena ensures easy movement along three sides of the swimming pool.

Full Description

A sliding door can be fitted in the vertical side wall, and a swing or sliding door may be placed in the end panels. The Ravena model is an interesting solution in terms of space and functionality of the enclosure. This model is particularly attractive for swimming pools located alongside buildings or existing walls. Its modern design and sleek appearance make it suitable for a variety of settings.

Technical parameters

  • Width of enclosure:4,00 - 7,50 m
  • Length of enclosure:6,40 - 16,00 m
  • Height of enclosure:2,20 - 3,00 m
  • Number of segments:3 - 7



Profile surfacing:

Silver
elox C-0 (silver)RAL 9006
White
white RAL 9010RAL 9010
Beige
beige RAL 1015RAL 1015
Anthracite
anthracite DB 703DB 703
Brown
brown - antiqueantique



Polycarbonate:

jednokomorový, čirý, 10 mm, NO DROP, s jednostrannou UV stabilizací, U = 3,1 W/m2K twin-wall, transparent, 10 mm, NO DROP, with one-side UV protection, U = 3,1 W/m2K



Guide rails:

guide rails in the full length of an enclosure
STANDARD - výška 28 mm

STANDARD - height 28 mm, surface - natural elox or beige RAL 1015

PROGRES - výška 15 mm PROGRES - height 15 mm, surface - natural elox or beige RAL 1015



  • the front face made from polycarbonate and aluminium profiles
  • 1 pcs of door according to the client´s request
  • draft seal on faces up to the height of 150mm
  • automatic locking system of segments STANDARD


406 ravena 01 800x600407 ravena 03 800x600408 ravena 05 800x600409 ravena 06 800x600410 ravena 09 800x600412 ravena 13 800x600411 ravena 11 800x600415 ravena 22 RU 800x600413 ravena 19 800x600414 ravena 21 800x600416 ravena 24 RU 800x600417 ravena 25 PL 800x600418 ravena 26 PL 800x600419 ravena 27 RU 800x600420 ravena 36 CZ 800x60036453 ravena 44 NZ 1 800x60036454 Ravena 54 B 1 800x60036455 Ravena 55 B 1 800x60036456 Ravena 61 CZ 1 800x60036457 Ravena 62 CZ 1 800x600
MaterialAluminium, Polycarbonate
Products categoriesPools, Spas, Domes , Enclosures
